JIS 5K Screw-Down Check Valve | Marine Flanged Combined Stop Check Valve

JIS 5K Screw-Down Check Valves

JIS 5K screw-down check valve integrates stop and check functions, the screw-down spindle can lock the disc to fully cut off flow while automatically preventing fluid backflow when opened. Made of integral cast bronze, it delivers excellent saltwater corrosion resistance and stable performance under 0.5MPa low pressure marine operating conditions.

Overview

Application: It is widely installed on cargo ships, fishing vessels and yachts for seawater, ballast water and fire water pipelines to avoid reverse flow damage to pumps and equipment. Matched with JIS 5K marine standard piping, it applies to marine auxiliary systems and coastal low-pressure water delivery projects requiring both shut-off and backflow protection.

Material Specification:

Part Name	Material	Code
1-Body	Cast Iron	FC20
2-Seat	Bronze	BC6
3-Disc	Bronze	BC6
4-Stem	Brass	C3771BD

Technical Specifications:

Nominal Diameter (DN)	Test Pressure MPa [kgf/cm2]
Nominal Diameter (DN)	Body	Seat
300 or less	1.03 [10.5]	0.76 [7.7]
350 and 400	0.88 [9]	0.65 [6.6]

Drawing:

JIS 5K Screw-Down Check Valves drawing.png

Dimensions:

Size	L	D	C	No.	h	t	H	D₂	kg
50	210	130	105	4	15	16	270	160	14.7
65	250	155	130	4	15	18	300	180	21.3
80	280	180	145	4	19	18	310	180	27.7
100	340	200	165	8	19	20	360	224	40.8
125	410	235	200	8	19	20	390	250	57.6
150	480	265	230	8	19	22	445	280	80.3
200	570	320	280	8	23	24	530	315	139
250	740	385	345	12	23	26	650	355	216
300	840	430	390	12	23	28	740	400	346
350	940	480	435	12	25	30	840	500	418
400	1050	540	495	16	25	30	940	630	600
