JIS 5K Angle Screw-Down Check Valves

Our JIS 5K bronze angle screw-down check valve integrates three functions in one corrosion-resistant bronze unit: 90-degree flow direction change, manual shut-off control, and automatic backflow prevention, manufactured to Japanese Industrial Standards for reliable low-pressure service in corrosive environments. Featuring a high-quality bronze body with flanged ends and a precision-machined bronze disc and seat, this space-saving valve offers superior durability compared to cast iron angle check valves in seawater and corrosive fluid applications at pipeline corners.

Overview

Application: Widely installed at 90-degree pipeline intersections on ships, offshore platforms and coastal facilities for seawater systems, cooling water circuits, brine lines and other corrosive fluid applications where cast iron angle check valves would suffer from accelerated corrosion and shortened service life. Also commonly used in desalination plants, chemical processing and Japanese-standard marine engineering projects throughout Southeast Asia, where space is limited and both flow direction change and backflow prevention are required in a single corrosion-resistant valve unit.

Material Specification:

Part Name	Material	Material Code
Body	Bronze	BC6
Disc	Bronze	BC6
Stem	Brass	C3771BD

Technical Specifications:

Nominal Pressure		5K
Hydraulic Inspection	Body	12 kg
Hydraulic Inspection	Seat	8 kg

Drawing:

JIS 5K Angle Screw-Down Check ValvesDRAW.jpg

Dimensions:

type	Size	L	D	C	No.	h	t	H	D₂
5K	15	55	80	60	4	12	9	120	80
	20	60	85	65	4	12	10	130	100
	25	65	95	75	4	12	10	145	125
	32	80	115	90	4	15	12	150	125
	40	85	120	95	4	15	12	165	140
	50	100	130	105	4	15	14	200	140
	65	115	155	130	4	15	14	220	160
